| HARDWARE FEATURES | |
|---|---|
| Interface | PCI Express |
| Dimensions ( W x D x H ) | 4.8 x 4.5 x 0.85 in. (120.8 x 115.2 x 21.5 mm) |
| Antenna Type | 2 Dual Band Detachable Antennas |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
| Frequency | 2.4GHz or 5GHz |
| Signal Rate | 867Mbps at 5GHz, 400Mbps at 2.4GHz |
| Reception Sensitivity | 5GHz :� 11a: -68dBm 11n HT20: -64dBm 11n HT40: -61dBm 11ac HT20: -59dBm 11ac HT40: -54dBm 11ac HT80: -51dBm 2.4GHz : 11b: -76dBm 11g: -68dBm 11n HT20: -64dBm 11n HT40: -61dBm |
| Transmit Power | 5GHz :� <23dBm (EIRP), 2.4GHz :� <20dBm (EIRP) |
| Wireless Modes | Ad-Hoc / Infrastructure mode |
| Wireless Security | Support 64/128 bit WEP, WPA-PSK/WPA2-PSK,802.1x |
| Modulation Technology | DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM |
| OTHERS | |
|---|---|
| System Requirements | Windows 11 (32/64bits), Windows 10 (32/64bits), Windows 8.1 (32/64bits), Windows 8 (32/64bits), Windows 7 (32/64bits), Windows XP(32/64bits) |
