Max overclocking frequency:
– 1DPC 1R Max speed up to 5333+ MHz
– 1DPC 2R Max speed up to 4800+ MHz
– 2DPC 1R Max speed up to 4400+ MHz
– 2DPC 2R Max speed up to 4000+ MHz

Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel Extreme Memory Profile (XMP)

4x M.2 slots (Key M)
M2_1 slot (From CPU)
– Supports up to PCIe 4.0 x4
– Supports 2242/2260/ 2280/ 22110 storage devices
M2_2 slot (From Z790 chipset)
– Supports up to PCIe 4.0 x4
– Supports 2242/ 2260/ 2280 storage devices
M2_3 & M2_4 slots (From Z790 chipset)
– Supports up to PCIe 4.0 x4
– Supports up to SATA 6Gb/s
– Supports 2242/ 2260/ 2280 storage devices

Supports Intel- Smart Response Technology for Intel Core-processors

System Connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Tuning Controller connector
1x TBT connector (Supports RTD3)

Jumpers
1x Clear CMOS jumper

LED Features
1x 4-pin RGB LED connector
3x 3-pin ARGB Gen2 LED connectors
4x EZ Debug LED

Thermal Features
– Extended Heatsink Design
– M.2 Shield Frozr
– K7 MOSFET thermal pad / Extra choke pad
– Fan headers (CPU + PUMP + SYSTEM)

Performance
– Core Boost
– VRM Power Design (VCPU / VGT / AUX)
– Dual CPU Power (2x 8 pin)
– Memory Boost
– Lightning Gen 5 PCI-E Slot
– Lightning Gen 4 PCI-E / M.2 Slot
– Front USB Type-C
– Server PCB
– 2oz Copper thickened PCB

DIY Friendly
– PCI-E Steel Armor
– Pre-installed I/O Shield
– EZ M.2 Clips
– EZ DEBUG LED
– EZ LED Control (Switch)
– Flash BIOS Button

RGB Support
– Mystic Light Extension (RGB)
– Mystic Light Extension (A-RAINBOW V2)
– Ambient Devices Support
