Features :
- Build in 3 steps AVR with wide input range of input 145VAC ~ 290VAC
- Output short circuit protection
- Overload protection
- Overcharge protection
- Sleek and compact design with CPU control
- Intelligent battery management
- Inverter compatible
- Boost and buck AVR for voltage stabilization
- Off-mode charging
- Cold start function
Technical Specification :
- Capacity 650VA
- Input Voltage range 145VAC ~ 290VAC (+/- 25% at line input)
- Input frequency 50 Hz
- Output Voltage range 195VAC ~ 255VAC
- Output frequency 50 Hz
- Rating Output Watt 300W
- Rating Output wave form Battery mode (Stepped wave)
- AC mode (Sine wave)
- Cold start (0 to 100% load) Press the ON/OFF switch
- Transfer time : 4 – 8 ms
- Battery rating 1 X 12V / 6.5Ah
- Battery type : Sealed, maintenance-free lead acid
- Charge current : about 1A at normal mode
- Backup time typical: 10 min to 15min (depending on load)
- Noise Level Less than 45dB
- Humidity 10 to 90% non condensing
- Weight 5.2Kg
