Memory
Max Memory
- 2GB soldered memory, not upgradable
- 3GB soldered memory, not upgradable
- 4GB soldered memory, not upgradable
Memory Type
LPDDR4x
Storage
Storage Support
- 32GB eMCP4x on systemboard
- 64GB eMCP4x on systemboard
- microSD card, supports FAT32 up to 256GB, exFAT up to 1TB
Storage Type
| Disk Type | Interface | Offering |
|---|---|---|
| Flash Memory | eMMC 5.1 | 32GB / 64GB |
Removable Storage
Card Reader**
- Nano-SIM + microSD card slot (WWAN models)
- microSD card slot (WLAN models)
Multi-Media
Speakers
2 side speakers, optimized with Dolby® Atmos®
Microphone
Dual-microphone array (with dedicated DSP)
Camera
Front 5.0MP, fixed focus, face unlock, rear 8.0MP, autofocus
VoiceCall
- Voice call[1]
- No support
Notes:
- 1. Use of Voice call requires cellular data plan. Voice call functionality details may vary based on local operator network, data and messaging services. Please contact your carriers for details.
Sensor
Vibration Motor
Eccentric Rotating Mass (ERM)
Sensors
- Accelerometer (G) sensor
- Ambient light sensor (ALS)
- Hall sensor
- Proximity (P) sensor
Battery
Battery
Integrated Li-Polymer 5000mAh (minimum) / 5100mAh (typical)
Max Battery Life[1]
Standby: 700 hr Online video playback: 8 hr Browsing: 10 hr
Charging Time[2]
Over 4.5 hr to fully charged
Notes:
- 1. All battery life claims are approximate and based on internal testing under optimal laboratory and network conditions. Actual battery performance will vary depending on numerous factors including product configuration and usage, software, operating conditions, wireless functionality, power management settings, screen brightness and other factors. The maximum capacity of the battery will naturally decrease with time and usage.
- 2. Charging data claim is approximate and based on internal testing under optimal laboratory. Actual result may vary owing to differences in product configuration, usage, software, operating conditions and other factors.
Power Adapter
Power Adapter
5V/2A (10W) AC adapter, 100-240V, 50-60Hz
DESIGN
Display
Display[1]
| Size | Resolution | Touch | Type | Brightness | Surface | Aspect Ratio | Color Gamut | Key Features |
|---|---|---|---|---|---|---|---|---|
| 10.1" | HD (1280x800) | Multi-touch | IPS | 400 nits | Anti-fingerprint | 16:10 | 60% NTSC | TÜV Low Blue Light |
Touchscreen
Capacitive-type multi-touch, supports 10-point touch
Notes:
- 1. IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.
Input Device
Pen
No support
Mechanical
Dimensions (WxDxH)[1]
Tablet: 241.54 x 149.38 x 8.25 mm (9.50 x 5.88 x 0.32 inches) Cradle: 125 x 92 x 17 mm (4.92 x 3.62 x 0.66 inches)
Weight[2]
Tablet: around 420 g (0.92 lbs) Cradle: 245 g (0.54 lbs)
Case Color
Iron grey
Case Material
Metal for back cover
Buttons
- Power button
- Volume button
Notes:
- 1. The system dimensions may vary depending on configurations.
- 2. The system weight is approximate and based on results in Lenovo lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
CONNECTIVITY
Network
WLAN + Bluetooth
802.11a/b/g/n/ac dual band 1x1 Wi-Fi® + Bluetooth® 5.0
WWAN
- 4G LTE
- No support
Cellular Bands
GSM: B2/B3/B5/B8 WCDMA: B1/B2/B5(B6/B19)/B8 FDD LTE: B1/B2/B3/B4/B5(B19)/B7/B8/B20/B28(a+b) TDD LTE: B38/B40
Wi-Fi Direct
Support
Wi-Fi Display
Support
FM Radio
FM Radio
Location Services**
| Models | Location |
|---|---|
| WLAN models | GPS + GLONASS |
| WWAN models | GPS + GLONASS + A-GPS |
Ports[1]
Standard Ports
- 1x USB-C® 2.0 (support data transfer and charging)
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Pogo pin connector (2-point)
Optional Ports**
- 1x Nano-SIM & microSD card slot (WWAN models)
- 1x microSD card slot (WLAN models)
Notes:
- 1. The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed. USB 2.0: 480 Mbit/s; USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s; USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s; USB4 20Gbps / USB 3.2 Gen 2x2 (SuperSpeed USB 20Gbps): 20 Gbit/s; USB4 40Gbps (USB 40Gbps): 40 Gbit/s; Thunderbolt 3/4: 40 Gbit/s.
SERVICE
Warranty
Base Warranty**[1]
- 1-year carry-in service
- 1-year mail-in service
- 1-year courier service
- 1-year Customer Replaceable Unit (CRU) service
- 2-year (1-yr battery) mail-in service
- 2-year (1-yr battery) carry-in service
- 2-year (2-yr battery) carry-in service
- 2-year (1-yr battery) courier service
- 2-year (2-yr battery) courier or carry-in service
- 3-year (1-yr battery) courier service
Notes:
- 1. For warranty upgrade service, please go to https://smartfind.lenovo.com/services. To learn more details of warranty policy, please access https://pcsupport.lenovo.com/warranty.
ENVIRONMENTAL
Operating Environment
Temperature
Operating: 0°C (32°F) to 40°C (104°F)
ACCESSORIES
Bundled Accessories
Bundled Accessories
Smart Charging Station (2-point pogo-pin charging connector)
SOFTWARE
Preinstalled Software
Preinstalled Software[1]
- Chrome
- Google Photos
- Phone by Google (cellular device only)
- Google Assistant
- Google Calendar
- Messages (cellular device only)
- YouTube Music
- Bing Wallpaper
- Dolby Atmos
- Kids Space
- Video +
Notes:
- 1. Actual application availability varies by country/region.
CERTIFICATIONS
Green Certifications[1]
Green Certifications
- (Optional) ENERGY STAR® 8.0
- RoHS compliant
Notes:
- 1. The items listed under the "Green Certifications" section may not only refer to certification but also registration or self-declaration.
Other Certifications
Other Certifications
TÜV Rheinland® Low Blue Light (Software Solution)
