Camera
Signal System: K/30, 1080p/30, 720p/30 etc.
Sensor: 1/2.5 inches, CMOS, Effective Pixels: 8.51 Megapixels
Optical Lens: 121° (DFOV), 110° (HFOV), 75° (VFOV), 5x zoom Horizontal/pitch ±15°
Digital Noise Reduction: 2D & 3D Digital Noise Reduction
Backlight Compensation: Support
PTZ: Mechanical PTZ (MPT) + e-PTZ (EPTZ)
SNR:≥ 55dB
Audio
Full-Frequency Speaker: 96 dB SPL at 0.5 m
Microphone Array: Beamforming microphone with 6m pickup distance
Expansion MIC: Support (Optional)
USB Features
Type of Connection: USB 3.0, downward compatible with USB 2.0
Color System / Compression: MJPEG / YUY2
USB Audio: 32K sampling rate, UAC 1.0 support
USB Video Communication Protocol: UVC 1.1
Interfaces
USB Interface: 1 x USB 3.0, Type -C; 1 x USB 2.0, Type -A
HD Output: 1x HDMI: Version 1.4b
Wireless: Bluetooth data communication (Bluetooth 5.0)
General Specifications
Power Supply: DC 12V, 2A (Max.)
Net Weight: 2.5Kg
Operating Temperature: 0 ~ 40° C
Storage Temperature: -40 ~ 60° C
Dimension: 600mm x 115mm x 135mm
(with bracket)
Others
Installation Method: Support desktop placement, wallmounting and TV-mounting etc
Supplied Cables: USB Cable
Safety Protection: Anti-Theft lock
