| Printer | |||
| Maximum Printing Resolution | 9600 (horizontal)*1 x 2400 (vertical) dpi | ||
| Print Head / Ink | Type: | Individual Ink Tank | |
| Number of Nozzles: | Total 5,120 nozzles | ||
| Ink Droplet Size: | 1pl | ||
| Ink Tank: | PGI-750 (Pigment Black), CLI-751 (Cyan / Magenta / Yellow / Black) [Optional: PGI-755XXL (Pigment Black), PGI-750XL (Pigment Black), CLI-751XL (Cyan / Magenta / Yellow / Black)] | ||
| Print Speed*2 Based on ISO / IEC 24734. Click here for summary report Click here for Document Print and Copy Speed Measurement Conditions | Document: Col | ESAT / Simplex | approx. 10.4 ipm |
| Document: B/W | ESAT / Simplex | approx. 14.5 ipm | |
| Photo (11 x 14" image) | PP-201 | approx. 120 sec | |
| Photo (4 x 6") | PP-201 / Borderless | approx. 36 sec | |
| Printable Width | Up to 322.2 mm (12.7 inch), Borderless: Up to 329 mm (13 inch) | ||
| Printable Area | Borderless Printing*3 | Top / Bottom / Right / Left margin: each 0 mm (Supported Paper Size: A3+, A3, A4, LTR, LDR, 4 x 6", 5 x 7", 8 x 10", 10 x 12") | |
| Bordered Printing | Top margin: 3 mm, Bottom margin: 5 mm, Left / Right margin: each 3.4 mm (LTR / LGL: Left: 6.4 mm, Right: 6.3 mm) | ||
| Recommended Printing Area | Top margin: 40.7 mm / Bottom margin: 37.4 mm | ||
| Paper Size | A3+, A3, A4, A5, B4, B5, LTR, LGL, LDR, 4 x 6", 5 x 7", 8 x 10", 10 x 12", Envelopes (DL, COM10), Custom size (width 55 - 329 mm, length 91 - 676 mm) * F4 is possible via custom size settings. | ||
| Paper Handling (Rear Tray) (Maximum Number) | Plain Paper | A3, A4, A5, B4, B5, LTR, LGL, LDR = 150 | |
| High Resolution Paper (HR-101N) | A3+ = 20, A3 = 50, A4 = 80 | ||
| Photo Paper Pro Platinum (PT-101) | A3+ = 1, A3, A4 = 10, 4 x 6" = 20 | ||
| Photo Paper Plus Glossy II (PP-201) | A3+ = 1, A3, A4 = 10, 4 x 6" = 20 | ||
| Photo Paper Pro Luster (LU-101) | A3+ = 1, A3, A4 = 10 | ||
| Photo Paper Plus Semi-Gloss (SG-201) | A3+ = 1, A3, A4, 8 x 10" = 10, 4 x 6" = 20 | ||
| Glossy Photo Paper "Everyday Use" (GP-601) | A4 = 10, 4 x 6" = 20 | ||
| Matte Photo Paper (MP-101) | A3, A4 = 10, 4 x 6" = 20 | ||
| Envelope | European DL / US Com. #10 = 10 | ||
| Paper Weight | Front Tray | Plain Paper: 64 - 105 g/m2, Canon specialty paper: max paper weight: approx. 300 g/m2 (Photo Paper Pro Platinum PT-101) | |
| Ink End Sensor | Optical sensor + Dot count | ||
| Print Head Alignment | Auto / Manual | ||
| System Requirements | |||
| Windows: | (Please visit www.canon-asia.com to check OS compatibility and to download the latest driver updates.) | Windows 8 / Windows 7 / Windows XP / Windows Vista | |
| Macintosh: | Mac OS X 10.6.8 and later | ||
| General Specifications | |||
| Interface | USB 2.0 Hi-Speed USB | ||
| Operating Environment | Temperature: 15 - 30°C; Humidity: 10 - 80% RH (no dew condensation) | ||
| Storage Environment | Temperature: 0 - 40°C; Humidity: 5 - 95% RH (no dew condensation) | ||
| Acoustic Noise (PC Print) | Photo (4 x 6")*5 | approx. 44.5 dB(A) | |
| Power | AC 100 - 240 V, 50/60 Hz | ||
| Power Consumption | Standby iX6770: USB connection to PC iX6870: Wireless LAN connection to PC | Approx. 0.8 W | |
| OFF: | Approx. 0.2 W | ||
| Printing*6 Wireless LAN connection to PC | Approx. 21 W | ||
| Environment | Regulation: | RoHS (EU, China), WEEE (EU) | |
| Eco-Label: | EPEAT | ||
| Duty Cycle | up to 12,000 pages/month | ||
| Dimension (W x D x H) | approx. 584 x 310 x 159 mm | ||
| Weight | approx. 8.1 kg | ||
